|Type:||Cutting Tools, Cutting Tool||Weight:||0.7 - 7.5|
|Application:||Cable Cutting||Cutting Range:||See The Table Below|
construction hand tools,
building construction tools
Use and Characteristic
1.cutting the different kinds of cable, wire etc.
2. Forged knife edge for long shelf and easy cutting.
3. Compact and light easy carrying.
4. Easy release and could stop at any position.
5. If knife return is necessary during cutting, let the movable handle lock and against the prop tooth block, then loosen the hand which gripes the handle, trun the swivel knife in counter clockwise.
|Product No.||Model Type||Cutting Range||Weight(kg)|
|80274||J40A||≤ 300mm2 copper and aluminum cable||0.96|
|80275||J40B||≤ 240mm2 copper and aluminum cable||0.7|
|80276||J40C||≤ 300mm2 copper and aluminum cable for the big cutter; the samll cutter is for the optical cable with one steel core||0.96|
|80277||J40||cutting ≤ 300mm2 Steel aluminum core armored cable; cutting 1000 couple telecommunication cable||1|
|80278||J75||cutting ≤ 3*120mm2 or Φ75mm steel aluminum core armored cable; cutting 3600 couple telecommunication cable||3.5|
|80279||J95||cutting ≤ 3*240mm2 or Φ95mm steel aluminum core armored cable||5.7|
|80280||J100||cutting ≤ 3*300 mm2 or Φ100mm steel aluminum core armored cable||6.5|
|80281||J130||cutting ≤ Φ130mm Multi core copper sheathed cable||7.5|
