| Brand Name: | XINYA |
| Model Number: | SA-QY-180 |
| MOQ: | 1 set |
| Price: | get latest price |
| Delivery Time: | 30-60 workdays after payment |
| Payment Terms: | L/C,T/T,,Western Union |
| Item | Product Model | SA-QY-180 |
|---|---|---|
| Performance Parameters | Rated Traction | 180kN |
| Maximum Traction | 216kN | |
| Rated Traction Speed | 2.5km/h | |
| Maximum Traction Speed | 5km/h | |
| Corresponding Traction Force | 90kN | |
| Structural Parameters | Traction Drum Bottom Diameter | 750mm |
| Number of Wire Grooves | 9~10 | |
| Pitch Distance | 62mm | |
| Groove Depth | 12mm | |
| Maximum Applicable Diameter of Wire | 30mm | |
| Dimensions | 4550*2200*2500mm | |
| Weight | 6000kg | |
| Main Configurations | Engine | FAMOUS DIESEL ENGINE |
| Electrical System | 24V | |
| Hydraulic Pump | REXROTH | |
| Hydraulic Motor | REXROTH | |
| Reducer | REXROTH | |
| Tailstock Winding Motor | DANFOSS | |
| Hydraulic Instrument | WIKA | |
| Main Hydraulic Valves | ATOS |
