Product Details:
|
| Application: | Power Construction | Usage: | Cable Pulling/Hoisting |
|---|---|---|---|
| Capacity: | 80KN | Engine: | Honda/Yamaha Engine |
| Weight(kg): | 180 | ||
| High Light: | gasoline powered winch,engine powered winch,Honda Gasoline Engine Cable Winch Puller |
||
8 Ton cable winch with Honda gasoline engine for power construction Cable Pulling/Hoisting
Application
1. It is used for tower erection
2. It is used for pole setting
3. Stringing wire in electrical power line construction.
Winch can be modified as per requirement, such as changing curve capstan into straight even cylindrical shape and coming with steel rope.
Cable winch is set up in the erect aerial cable and underground wiring necessary tight lines, poles and other construction products, in a variety of complex environment, easy to set up wire lifting, traction or tight line.
Widely used in electric power, telecommunications, municipal engineering construction of the tight line of towers or mobile line, applicable to the field without electricity. The actual operation proved that the structure is reasonable, small size, light weight, power, noise, flexible operation, easy handling, etc., praised by the majority of users.
Technical Data
| Model | Pull Force(KN) | Speed(m/min) | Engine | Weight(kg) |
| JJM8Q | 80 | 4 | Honda/YAMAHA | 180 |
| 40 | 8 | |||
| No lifting | 3.8 |
Practical Application
